#include <op_encodings.hh>

Inheritance diagram for gem5::Gcn3ISA::Inst_VOP1:

Public Member Functions
	Inst_VOP1 (InFmt_VOP1 *, const std::string &opcode)

	~Inst_VOP1 ()

int	instSize () const override

void	generateDisassembly () override

void	initOperandInfo () override

Public Member Functions inherited from gem5::Gcn3ISA::GCN3GPUStaticInst
	GCN3GPUStaticInst (const std::string &opcode)

	~GCN3GPUStaticInst ()

bool	isFlatScratchRegister (int opIdx) override

bool	isExecMaskRegister (int opIdx) override

int	getOperandSize (int opIdx) override

int	coalescerTokenCount () const override
	Return the number of tokens needed by the coalescer. More...

ScalarRegU32	srcLiteral () const override

Public Member Functions inherited from gem5::GPUStaticInst
	GPUStaticInst (const std::string &opcode)

virtual	~GPUStaticInst ()

void	instAddr (int inst_addr)

int	instAddr () const

int	nextInstAddr () const

void	instNum (int num)

int	instNum ()

void	ipdInstNum (int num)

int	ipdInstNum () const

void	initDynOperandInfo (Wavefront wf, ComputeUnit cu)

virtual void	execute (GPUDynInstPtr gpuDynInst)=0

const std::string &	disassemble ()

virtual int	getNumOperands ()=0

virtual int	numDstRegOperands ()=0

virtual int	numSrcRegOperands ()=0

int	numSrcVecOperands ()

int	numDstVecOperands ()

int	numSrcVecDWords ()

int	numDstVecDWords ()

int	numSrcScalarOperands ()

int	numDstScalarOperands ()

int	numSrcScalarDWords ()

int	numDstScalarDWords ()

int	maxOperandSize ()

bool	isALU () const

bool	isBranch () const

bool	isCondBranch () const

bool	isNop () const

bool	isReturn () const

bool	isEndOfKernel () const

bool	isKernelLaunch () const

bool	isSDWAInst () const

bool	isDPPInst () const

bool	isUnconditionalJump () const

bool	isSpecialOp () const

bool	isWaitcnt () const

bool	isSleep () const

bool	isBarrier () const

bool	isMemSync () const

bool	isMemRef () const

bool	isFlat () const

bool	isFlatGlobal () const

bool	isLoad () const

bool	isStore () const

bool	isAtomic () const

bool	isAtomicNoRet () const

bool	isAtomicRet () const

bool	isScalar () const

bool	readsSCC () const

bool	writesSCC () const

bool	readsVCC () const

bool	writesVCC () const

bool	readsEXEC () const

bool	writesEXEC () const

bool	readsMode () const

bool	writesMode () const

bool	ignoreExec () const

bool	isAtomicAnd () const

bool	isAtomicOr () const

bool	isAtomicXor () const

bool	isAtomicCAS () const

bool	isAtomicExch () const

bool	isAtomicAdd () const

bool	isAtomicSub () const

bool	isAtomicInc () const

bool	isAtomicDec () const

bool	isAtomicMax () const

bool	isAtomicMin () const

bool	isArgLoad () const

bool	isGlobalMem () const

bool	isLocalMem () const

bool	isArgSeg () const

bool	isGlobalSeg () const

bool	isGroupSeg () const

bool	isKernArgSeg () const

bool	isPrivateSeg () const

bool	isReadOnlySeg () const

bool	isSpillSeg () const

bool	isGloballyCoherent () const
	Coherence domain of a memory instruction. More...

bool	isSystemCoherent () const

bool	isF16 () const

bool	isF32 () const

bool	isF64 () const

bool	isFMA () const

bool	isMAC () const

bool	isMAD () const

virtual void	initiateAcc (GPUDynInstPtr gpuDynInst)

virtual void	completeAcc (GPUDynInstPtr gpuDynInst)

virtual uint32_t	getTargetPc ()

void	setFlag (Flags flag)

const std::string &	opcode () const

const std::vector< OperandInfo > &	srcOperands () const

const std::vector< OperandInfo > &	dstOperands () const

const std::vector< OperandInfo > &	srcVecRegOperands () const

const std::vector< OperandInfo > &	dstVecRegOperands () const

const std::vector< OperandInfo > &	srcScalarRegOperands () const

const std::vector< OperandInfo > &	dstScalarRegOperands () const

Protected Attributes
InFmt_VOP1	instData

InstFormat	extData

uint32_t	varSize

Protected Attributes inherited from gem5::Gcn3ISA::GCN3GPUStaticInst
ScalarRegU32	_srcLiteral
	if the instruction has a src literal - an immediate value that is part of the instruction stream - we store that here More...

Protected Attributes inherited from gem5::GPUStaticInst
const std::string	_opcode

std::string	disassembly

int	_instNum

int	_instAddr

std::vector< OperandInfo >	srcOps

std::vector< OperandInfo >	dstOps

Private Member Functions
bool	hasSecondDword (InFmt_VOP1 *)

Additional Inherited Members
Public Types inherited from gem5::GPUStaticInst
enum	OpType { SRC_VEC, SRC_SCALAR, DST_VEC, DST_SCALAR }

typedef int(RegisterManager::*	MapRegFn) (Wavefront *, int)

Public Attributes inherited from gem5::GPUStaticInst
enums::StorageClassType	executed_as

Static Public Attributes inherited from gem5::GPUStaticInst
static uint64_t	dynamic_id_count

Protected Member Functions inherited from gem5::Gcn3ISA::GCN3GPUStaticInst
void	panicUnimplemented () const

Detailed Description

Definition at line 279 of file op_encodings.hh.

Constructor & Destructor Documentation

◆ Inst_VOP1()

gem5::Gcn3ISA::Inst_VOP1::Inst_VOP1	(	InFmt_VOP1 *	iFmt,
		const std::string &	opcode
	)

Definition at line 723 of file op_encodings.cc.

References gem5::Gcn3ISA::GCN3GPUStaticInst::_srcLiteral, extData, hasSecondDword(), instData, gem5::Gcn3ISA::REG_SRC_DPP, gem5::Gcn3ISA::REG_SRC_SWDA, gem5::GPUStaticInst::setFlag(), gem5::Gcn3ISA::InFmt_VOP1::SRC0, and varSize.

◆ ~Inst_VOP1()

gem5::Gcn3ISA::Inst_VOP1::~Inst_VOP1 ( )

Definition at line 743 of file op_encodings.cc.

Member Function Documentation

◆ generateDisassembly()

void gem5::Gcn3ISA::Inst_VOP1::generateDisassembly ( )

overridevirtual

Reimplemented from gem5::Gcn3ISA::GCN3GPUStaticInst.

Definition at line 796 of file op_encodings.cc.

References gem5::GPUStaticInst::_opcode, gem5::Gcn3ISA::GCN3GPUStaticInst::_srcLiteral, gem5::GPUStaticInst::disassembly, instData, gem5::Gcn3ISA::opSelectorToRegSym(), gem5::Gcn3ISA::REG_SRC_DPP, gem5::Gcn3ISA::REG_SRC_LITERAL, gem5::Gcn3ISA::REG_SRC_SWDA, gem5::Gcn3ISA::InFmt_VOP1::SRC0, and gem5::Gcn3ISA::InFmt_VOP1::VDST.

◆ hasSecondDword()

bool gem5::Gcn3ISA::Inst_VOP1::hasSecondDword ( InFmt_VOP1 * iFmt )

private

Definition at line 777 of file op_encodings.cc.

References gem5::Gcn3ISA::REG_SRC_DPP, gem5::Gcn3ISA::REG_SRC_LITERAL, gem5::Gcn3ISA::REG_SRC_SWDA, and gem5::Gcn3ISA::InFmt_VOP1::SRC0.

Referenced by Inst_VOP1().

◆ initOperandInfo()

void gem5::Gcn3ISA::Inst_VOP1::initOperandInfo ( )

overridevirtual

Reimplemented from gem5::Gcn3ISA::GCN3GPUStaticInst.

Definition at line 748 of file op_encodings.cc.

References gem5::GPUStaticInst::dstOps, gem5::Gcn3ISA::GCN3GPUStaticInst::getOperandSize(), instData, gem5::Gcn3ISA::isScalarReg(), gem5::Gcn3ISA::isVectorReg(), gem5::GPUStaticInst::numDstRegOperands(), gem5::GPUStaticInst::numSrcRegOperands(), gem5::X86ISA::reg, gem5::Gcn3ISA::InFmt_VOP1::SRC0, gem5::GPUStaticInst::srcOps, and gem5::Gcn3ISA::InFmt_VOP1::VDST.

◆ instSize()

int gem5::Gcn3ISA::Inst_VOP1::instSize ( ) const

overridevirtual

Implements gem5::GPUStaticInst.

Definition at line 771 of file op_encodings.cc.

References varSize.

Member Data Documentation

◆ extData

InstFormat gem5::Gcn3ISA::Inst_VOP1::extData

protected

Definition at line 294 of file op_encodings.hh.

Referenced by gem5::Gcn3ISA::Inst_VOP1__V_MOV_B32::execute(), and Inst_VOP1().

◆ instData

InFmt_VOP1 gem5::Gcn3ISA::Inst_VOP1::instData

protected

Definition at line 292 of file op_encodings.hh.

◆ varSize

uint32_t gem5::Gcn3ISA::Inst_VOP1::varSize

protected

Definition at line 295 of file op_encodings.hh.

Referenced by Inst_VOP1(), and instSize().

The documentation for this class was generated from the following files:

arch/amdgpu/gcn3/insts/op_encodings.hh
arch/amdgpu/gcn3/insts/op_encodings.cc
