Entry data type for the Active Generation Table (AGT) and the Pattern Sequence Table (PST) More...
Classes | |
| struct | SequenceEntry |
| Sequence entry data type. More... | |
Public Member Functions | |
| ActiveGenerationTableEntry (int num_positions) | |
| void | invalidate () override |
| Invalidate the block. More... | |
| void | update (ActiveGenerationTableEntry const &e) |
| Update the entry data with an entry from a generation that just ended. More... | |
| void | addOffset (unsigned int offset) |
| Add a new access to the sequence. More... | |
 Public Member Functions inherited from gem5::TaggedEntry | |
| TaggedEntry () | |
| ~TaggedEntry ()=default | |
| virtual bool | isValid () const |
| Checks if the entry is valid. More... | |
| bool | isSecure () const |
| Check if this block holds data from the secure memory space. More... | |
| virtual Addr | getTag () const |
| Get tag associated to this block. More... | |
| virtual bool | matchTag (Addr tag, bool is_secure) const |
| Checks if the given tag information corresponds to this entry's. More... | |
| virtual void | insert (const Addr tag, const bool is_secure) |
| Insert the block by assigning it a tag and marking it valid. More... | |
| std::string | print () const override |
| Prints relevant information about this entry. More... | |
| Public Member Functions inherited from gem5::ReplaceableEntry | |
| ReplaceableEntry ()=default | |
| virtual | ~ReplaceableEntry ()=default |
| virtual void | setPosition (const uint32_t set, const uint32_t way) |
| Set both the set and way. More... | |
| uint32_t | getSet () const |
| Get set number. More... | |
| uint32_t | getWay () const |
| Get way number. More... | |
Public Attributes | |
| Addr | paddress |
| Physical address of the spatial region. More... | |
| Addr | pc |
| PC that started this generation. More... | |
| unsigned int | seqCounter |
| Counter to keep track of the interleaving between sequences. More... | |
| std::vector< SequenceEntry > | sequence |
| Sequence of accesses. More... | |
| Public Attributes inherited from gem5::ReplaceableEntry | |
| std::shared_ptr< replacement_policy::ReplacementData > | replacementData |
| Replacement data associated to this entry. More... | |
Additional Inherited Members | |
| Protected Member Functions inherited from gem5::TaggedEntry | |
| virtual void | setTag (Addr tag) |
| Set tag associated to this block. More... | |
| virtual void | setSecure () |
| Set secure bit. More... | |
| virtual void | setValid () |
| Set valid bit. More... | |
| Protected Attributes inherited from gem5::ReplaceableEntry | |
| uint32_t | _set |
| Set to which this entry belongs. More... | |
| uint32_t | _way |
| Way (relative position within the set) to which this entry belongs. More... | |
Detailed Description
Entry data type for the Active Generation Table (AGT) and the Pattern Sequence Table (PST)
Definition at line 73 of file spatio_temporal_memory_streaming.hh.
Constructor & Destructor Documentation
◆ ActiveGenerationTableEntry()
|
inline |
Definition at line 97 of file spatio_temporal_memory_streaming.hh.
Member Function Documentation
◆ addOffset()
|
inline |
Add a new access to the sequence.
- Parameters
-
offset offset in cachelines within the spatial region
Definition at line 135 of file spatio_temporal_memory_streaming.hh.
References gem5::ArmISA::offset, seqCounter, and sequence.
Referenced by gem5::prefetch::STeMS::calculatePrefetch().
◆ invalidate()
|
inlineoverridevirtual |
Invalidate the block.
Its contents are no longer valid.
Reimplemented from gem5::TaggedEntry.
Definition at line 104 of file spatio_temporal_memory_streaming.hh.
References gem5::TaggedEntry::invalidate(), paddress, pc, seqCounter, and sequence.
◆ update()
|
inline |
Update the entry data with an entry from a generation that just ended.
This operation can not be done with the copy constructor, becasuse the TaggedEntry component must not be copied.
- Parameters
-
e entry which generation has ended
Definition at line 123 of file spatio_temporal_memory_streaming.hh.
References gem5::ArmISA::e, paddress, pc, seqCounter, and sequence.
Referenced by gem5::prefetch::STeMS::checkForActiveGenerationsEnd().
Member Data Documentation
◆ paddress
| Addr gem5::prefetch::STeMS::ActiveGenerationTableEntry::paddress |
Physical address of the spatial region.
Definition at line 76 of file spatio_temporal_memory_streaming.hh.
Referenced by gem5::prefetch::STeMS::calculatePrefetch(), invalidate(), and update().
◆ pc
| Addr gem5::prefetch::STeMS::ActiveGenerationTableEntry::pc |
PC that started this generation.
Definition at line 78 of file spatio_temporal_memory_streaming.hh.
Referenced by gem5::prefetch::STeMS::calculatePrefetch(), invalidate(), and update().
◆ seqCounter
| unsigned int gem5::prefetch::STeMS::ActiveGenerationTableEntry::seqCounter |
Counter to keep track of the interleaving between sequences.
Definition at line 80 of file spatio_temporal_memory_streaming.hh.
Referenced by addOffset(), invalidate(), and update().
◆ sequence
| std::vector<SequenceEntry> gem5::prefetch::STeMS::ActiveGenerationTableEntry::sequence |
Sequence of accesses.
Definition at line 95 of file spatio_temporal_memory_streaming.hh.
Referenced by addOffset(), invalidate(), gem5::prefetch::STeMS::reconstructSequence(), and update().
The documentation for this struct was generated from the following file:
- mem/cache/prefetch/spatio_temporal_memory_streaming.hh
